Hewlett Packard Enterprise ProLiant DL20 Gen9 server 3.7 GHz Intel Xeon E3 v6 E3-1240V6 Rack (1U) 290 W
SKU:871430-B21
In Stock
Optimized Reliable Solution
- The HPE ProLiant DL20 Gen9 Server is a 1P 1U rack server that combines the right balance of performance, expandability, reliability and manageability for a variety of business needs.
- The DL20 Gen9 Server combines a dense and compact form factor with redundant power supply capability which keeps your business running and provides data protection and accessibility even in the event of a power supply failure.
- Customers can protect against data loss and downtime with the enhanced error handing of HPE DDR4 ECC memory options while also improving workload performance and power efficiency.
- Trusted and proven HPE Smart Array technology provides businesses with protection for critical data through RAID mirroring and striping capability and, with FBWC up to 4 GB, captures and holds data indefinitely in the event of a power loss, equipment failure, or human error.
- Your business cannot afford disruptions due to downtime on your server. HPE Insight Online with HPE Insight Remote Support provides 24x7 remote monitoring with anywhere, anytime personalized access to your IT and support status to get your business up and running.
- 100% Secure
- 100% Money-Back Guarantee
- Best Price
- PayPal world seller
| Processor | |
|---|---|
| Thermal Monitoring Technologies | Yes |
| Thermal Design Power (TDP) | 72 W |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Stepping | B0 |
| Scalability | 1S |
| Processor threads | 8 |
| Processor package size | 37.5 x 37.5 mm |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Kaby Lake |
| Processor code | SR327 |
| PCI Express configurations | 1x16,1x8+2x4,2x8 |
| Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
| Memory clock speeds supported by processor | 1866,2400 MHz |
| Memory channels supported by processor | Dual |
| Memory bandwidth supported by processor (max) | 37.5 GB/s |
| Maximum number of PCI Express lanes | 16 |
| Maximum internal memory supported by processor | 64 GB |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| ECC supported by processor | Yes |
| Bus type | DMI3 |
| Processor cache type | Smart Cache |
| Processor cache | 8 MB |
| Conflict Free processor | Yes |
| Processor frequency | 3.7 GHz |
| Processor boost frequency | 4.1 GHz |
| Number of processors installed | 1 |
| Processor model | E3-1240V6 |
| System bus rate | 8 GT/s |
| Processor socket | LGA 1151 (Socket H4) |
| Processor cores | 4 |
| Motherboard chipset | Intel® C232 |
| Processor family | Intel® Xeon® E3 v6 |
| Memory | |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4 DIMM |
| Memory clock speed | 2400 MHz |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Storage | |
| Supported storage drive interfaces | Serial ATA |
| Supported HDD sizes | 2.5" |
| RAID support | Yes |
| RAID levels | 0,1,5 |
| Number of HDDs supported | 4 |
| Maximum storage capacity | 8 TB |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Optical drive type | No |
| Chassis type | Rack (1U) |
| Performance | |
| Compatible operating systems | Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware |
| Operating system installed | No |
| Software | |
| Compatible operating systems | Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware |
| Operating system installed | No |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Secure Key | Yes |
| Intel® Quick Sync Video Technology | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel Clear Video Technology | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 97469 |
| CPU configuration (max) | 1 |
| Power | |
| Number of main power supplies | 1 |
| Redundant power supply (RPS) support | No |
| Power supply | 290 W |
| Certificates | |
| Energy Star certified | Yes |
| Technical details | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Supported HDD sizes | 2.5" |
| Ethernet interface type | Gigabit Ethernet |
| CPU configuration (max) | 1 |
| Chassis type | Rack (1U) |
| Weight & dimensions | |
| Width | 434.6 mm |
| Weight | 8.7 kg |
| Height | 43.2 mm |
| Depth | 382.2 mm |
| Other features | |
| CPU configuration (max) | 1 |
| Part No | 871430-B21 |
|---|---|
| Manufacturer | HP |
